SS Rotary Drum Fine Screen for booster pump stations

More Views

SS Rotary Drum Fine Screen for booster pump stationsSS Rotary Drum Fine Screen for booster pump stationsSS Rotary Drum Fine Screen for booster pump stations

SS Rotary Drum Fine Screen for booster pump stations

Category:Wedge Wire Pipe&Cylinder
Material:Stainless steel 302,304,304L,316,316L
Properties:Wedge Wire Pipe
Application:waste water treatment, crude oil and natural gas production and vessel internals solving problems of solid

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:yolanda

Detailed description of the SS Rotary Drum Fine Screen for booster pump stations

    The rotating screen is a mechanical self-cleaning device that was developed to meet the growing need and demand for an efficient and economical method of removing suspended solids from mixed liquid streams. The continuous and self-cleaning effect of the rotating screens makes it possible to use higher flow capacities than those of any other type of screen thus resulting in substantial savings with respect to both investment and maintenance.

Application for SS Rotary Drum Fine Screen for booster pump stations:

Stainless steel Wedge wire screen cylinders can be used in waste water filtration, food processing, pulp and paper as well as mineral processing applications. Wedge wire or profile screen half cylinders can be added to an auger or screw press to separate solids from liquids in food, waste water, minerals and industrial grit/chips from coolant.

Features for SS Rotary Drum Fine Screen for booster pump stations:

1. High efficiency and high performance
2. Easy to move and install
3. Easy and convenient operation
4. Strong body

In Hot Selling All The World :

Malaysia ; Singapore ; Philippines ; Vietnam; India ; Turkey ; Kuwait;Poland ; Holland ; Bulgaria ; Macedonia ;The USA ; Australian ; Brazil ; Romanian ;Saudi Arabia ; Iran ; Thailand ; Pakistan ; South Africa;

SS Rotary Drum Fine Screen for booster pump stations

The specifications of the SS Rotary Drum Fine Screen for booster pump stations:

SS Rotary Drum Fine Screen for booster pump stations

Basepipe OD (in)
Perforations per foot
Basepipe Hole Size (in)
Open Area of Basepipe Holes (in2/ft)
Wrap Wire Size Keystone (in)
Rib Wire Size Round (in)
Maximum OD (in)
1.05
54
0.312
4.14
0.09*0.09
0.125
1.489
1.315
66
0.312
5.06
0.09*0.09
0.125
1.726
1.66
78
0.312
5.98
0.09*0.09
0.125
2.126
1.90
42
0.375
4.63
0.09*0.09
0.125
2.387
2.063
42
0.375
4.63
0.09*0.09
0.125
2.55
2.375
54
0.375
5.96
0.09*0.09
0.125
2.86
2.875
66
0.375
7.28
0.09*0.09
0.125
3.362
3.25
78
0.375
8.61
0.09*0.09
0.125
3.737
3.50
78
0.375
8.61
0.09*0.09
0.125
3.987
4.00
90
0.375
9.94
0.09*0.09
0.125
4.487
4.50
102
0.375
11.26
0.09*0.09
0.125
5.001
5.00
114
0.375
12.59
0.09*0.09
0.125
5.506



The Packaging and Transportation of the SS Rotary Drum Fine Screen for booster pump stations:

SS Rotary Drum Fine Screen for booster pump stations

SS Rotary Drum Fine Screen for booster pump stations
