Wedge wire false bottom lauter tun screen plate for beer brewery

More Views

Wedge wire false bottom lauter tun screen plate for beer breweryWedge wire false bottom lauter tun screen plate for beer breweryWedge wire false bottom lauter tun screen plate for beer brewery

Wedge wire false bottom lauter tun screen plate for beer brewery

Category:Wedge Wire Screen Panel
Material:stainless steel 304,304L,316,316L,321,430 or as per your request.
Properties:lauter tun screen
Application:water-treatment,beer brewing,water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant, refining & petrochemical

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:yolanda

Detailed description of the Wedge wire false bottom lauter tun screen plate for beer brewery

Brewing beer requires a lot of steps before the final product can be achieved. One of the important steps in brewing beer is mashing. Mashing refers to the hot water steeping process. It is necessary not only in hydrating the grains but also activating the malt enzymes so that the grain starches are converted to fermentable sugars. Without the process of mashing, the grain bills will not produce enough sugar for the liquid wort to ferment.

In the lautering process, the wort (the liquid containing the sugar extracted during mashing) is separated from the grains. This is done either in a lauter tun outfitted with a Wedge wire false bottom lauter tun screen plate or in a mash filter. Most separation processes have two stages: first wort run-off, during which the extract is separated in an undiluted state from the spent grains, and sparging, in which extract which remains with the grains is rinsed off with hot water. The Wedge wire false bottom lauter tun screen plate is designed to hold back the large bits of grist and hulls. The bed of grist that settles on it is the actual filter. Lauter tuns have provisions for rotating rakes to cut into the bed of grist to maintain good flow. When the process is complete, a plow can be dropped to drive the spent grain out of the vessel.

Wedge wire false bottom lauter tun screen plate for beer brewery

Wedge wire false bottom lauter tun screen plate for beer brewery

Usages of Wedge wire false bottom lauter tun screen plate for beer brewery

tis screen panel is used in the field of sugar juice filtration, waste water treatment, crude oil and natural gas production and vessel internals solving problems of solid / liquid and solid / gas separation; filtration of oils, greases, paints, food products, fuels, liquid cooling agents, chemicals etc.

Wedge wire false bottom lauter tun screen plate for beer brewery

Characteristic of Wedge wire false bottom lauter tun screen plate for beer brewery

1. A continuous slot opening which significantly increases the available open area, thus providing a greater access to the water bearing zone.
2. A 'V' shaped wedge wire which avoids clogging and ensures uninterrupted flow.
3. A uniform and efficient well development due to the continuous slot opening.
4. Offering great strength. precision, long service life

Wedge wire false bottom lauter tun screen plate for beer brewery

The specifications of the Wedge wire false bottom lauter tun screen plate for beer brewery:

Wedge wire false bottom lauter tun screen plate for beer brewery

Normal Name

Lauter Tun Screen, Mash Tun Screen, False Bottom Screen, Etc.

Diameter Range

(MM)

200mm To 2500mm. Diameter Customized

Normal Diameter

(MM)

29”, 30”, 35”, 37”, 40”, 45”, 47”, 59”, 63”, 74”, Etc

Normal Slot

(MM)

0.7mm, 0.75mm, 0.8mm, 1.0mm, customized

Normal Thickness (MM)

8.5mm, 20mm. 25mm, 30mm, 40mm, 50mm, Customized.



Sections & shape

1 Cycle, 2 PCS, 3 PCS, 4 PCS, 6 PCS, 8 PCS. Customized

Wedge wire

(MM)

2x4MM Wedge Wire, 3x5MM Wedge Wire

Support Rod

 (MM)

3x5MM V shaped Support Rod, 3x5mm Square Support Rod

Strengthen Rod

(MM)

Thickness and Height according to the diameter and screen thickness

Note

Usually customized.

The Packaging and Transportation of the Wedge wire false bottom lauter tun screen plate for beer brewery:

Wedge wire false bottom lauter tun screen plate for beer brewery
