Quality Wedge Wire Screen Manufacturer in China

stainless steel wedge wire sink strainer baskets

More Views

stainless steel wedge wire sink strainer basketsstainless steel wedge wire sink strainer basketsstainless steel wedge wire sink strainer baskets

stainless steel wedge wire sink strainer baskets

Category:Wedge Wire Screen Basket
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:wedge wire screen
Application:water-treatment , water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:Enla

Details of stainless steel wedge wire sink strainer baskets

UBO Filter Company manufactures stainless steel wedge wire sink strainer baskets for Pulp, paper and recycling industries. Customers in these industries use our screens for water clarification, cleaning, dewatering, pulp screening and fractionation, fiber retention, drying and other liquid/solid separation processes.

stainless steel wedge wire sink strainer baskets

Applications of stainless steel wedge wire sink strainer baskets

The wedge wire screen cylinders can be used as rotary screens.
Wedge wire screen cylinders are widely used in the mine, coal, mineral and other applications for heavy duty and high load filtering, sizing and screening.

Feature of stainless steel wedge wire sink strainer baskets

It is a common screen basket. Its main feature is that high mechanical strength, smoothness and tolerance sccuracy. It is suitable for the high consistency pulp screen and before the head box.

stainless steel 316 wedge wire screen cylinder basket is SS316L after mechanical polishing. Good processing technology
ensures fit precision of wedge bar and reinforce ring and make sure the evenness of
screen cut.

Characteristics of stainless steel wedge wire sink strainer baskets

High weld strength
Higher accuracy and consistency of wire gap
Lower surface roughness
Single piece cylinder construction (As opposed to welded patched cylinders)
Axially-seamless cylinder construction

stainless steel wedge wire sink strainer baskets

Specifications of stainless steel wedge wire sink strainer baskets:

stainless steel wedge wire sink strainer baskets



Specification (wedge wire):

Width(mm): 1.50 1.80 2.30 3.00 3.30 3.70

Height(mm): 2.20 2.50 2.70 3.60 4.30 4.70 5.60 6.30 7.00

Specification (support rod):

Width(mm): 2.30 3.00 3.30 3.70

Height(mm): 2.70 3.60 4.70 5.60 6.30

Note: other specifications available as per request

Slot size

0.10, 0.15, 0.20, 0.25, 0.30…… 6.00mm also achieved upon request.

Material:

galvanized low carton (LCG), stainless steel (304,316 etc.)

Length

up to 6 meters.

Diameter

from 25mm to 1200mm.

End connection

Plain beveled ends, flanged or threaded couplings

Packaging and Transportation of stainless steel wedge wire sink strainer baskets:

transportation
