Wedge wire screen resin trap filter manufacturer

More Views

Wedge wire screen resin trap filter manufacturerWedge wire screen resin trap filter manufacturerWedge wire screen resin trap filter manufacturer

Wedge wire screen resin trap filter manufacturer

Category:Resin Traps
Material:stainless steel 304,304L,316,316L,321,430 or as per your request.
Properties:resin trap
Application:water-treatment,beer brewing,water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant, refining & petrochemical

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:yolanda

Detailed description of the Wedge wire screen resin trap filter manufacturer

Wedge wire screen resin trap filters are placed in a housing, inline with the flow to capture expensive media from traveling downstream. We can design the resin trap filter to capture media particles of any size. With the continuous open slot, the traps provide sufficient open area to let process flow move smoothly thus minimizing pressure loss through the system.
Your resin trap can be designed to suit either new or existing strainer bodies.

UBO wedge wire resin trap provide a high percentage of open area thus minimizing pressure loss through the system. Your resin trap can be designed to suit either new or existing strainer bodies.

Wedge wire screen resin trap filter manufacturer

Wedge wire screen resin trap filter manufacturer

Wedge wire screen resin trap filter manufacturer

Application of Wedge wire screen resin trap filter manufacturer

Welded stainless steel water well screen pipes are mainly used for the water-treatment , water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant ,sewage treatment and other industries,water,oil or gas filter and other filtration equipment.

Characteristics of Wedge wire screen resin trap filter manufacturer

1. Filter made of stainless steel trapezoidal wire, screen slot is v-shape, can effectively intercept resin impurities.
2. Trapezoidal wire evenly circumferentially array on the support bar,ensure the screen filter area and non-obstructive, avoiding impurities concentrated.
3. Resin trap all connected by welding, durable, long life.
4. After working for some time,can filter backwash, multiple use.

Wedge wire screen resin trap filter manufacturer

Wedge wire screen resin trap filter manufacturer

The specifications of the Wedge wire screen resin trap filter manufacturer:

Wedge wire screen resin trap filter manufacturer

Material SS304, SS304L, SS316, SS316L, SS321, Duplex, Hastelloy, etc
OD Range 25mm-2000mm
ID Range 19mm-1981mm
Length Range Up to 6000 mm
Slot Range 20 micron to 3000 micron (Tolerance:+-5 micron)
Wedge Wire 0.5x1.5 0.75x1.5 1x2 1.5*2 2x3 2*4
Support Rod 1.5x2.5
2x3
1.5x2.5
2x3
1.5x2.5
2x3
1.8*2.5
2x3
3*5 3*5
Connection Flange and thread
End Type Closed plate
Note Customized According To Special Requirement

The Packaging and Transportation of the Wedge wire screen resin trap filter manufacturer:

transportation of Wedge wire screen resin trap filter manufacturer
