Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap

More Views

Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin TrapStainless Steel Wire Wrapped Filter Screens Water Treatment Resin TrapStainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap

Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap

Category:Resin Traps
Material:stainless steel 304,304L,316,316L,321,430 or as per your request.
Properties:resin trap
Application:water-treatment,beer brewing,water well drilling ,oil well drilling ,mineral processing, coal-cleaning plant,refining & petrochemical

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:yolanda

Detailed description of the Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap

Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap is made up of rods and warp. The rod can be round wire, triangular wire or trapezoid wire.
The warp is triangular wire (V-shaped wire). The Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap have a robust structure and large open area, as well as accurate slot dimension. At the same time, wedge wire screens pipe have many advantages such as heat-resisting, anti-corrosive, good machine capability,long service life, safety and reliability and so on. It can be used in many kinds of medium filtering.

Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap

Features of Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap

1. High efficiency and high performance
2. Easy to move and install
3. Easy and convenient operation
4. Strong body

Application of Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap

A resin trap is normally used: to capture expensive resin that escapes from a treatment vessel by accident, to protect equipment further downstream. A strainer is often used in tubes to block unwanted particles or dirt that would otherwise damage downstream equipment. Cleaning is carried out by removing the strainer from the tube.

Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap

Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap

The specifications of the Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap:

Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap

Material

SS304, SS304L, SS316, SS316L, SS321, Duplex, Hastelloy, etc

OD Range

25mm-2000mm

ID Range

19mm-1981mm

Length Range

Up to 6000 mm

Slot Range

20 micron to 3000 micron (Tolerance:+-5 micron)

Wedge Wire

0.5x1.5

0.75x1.5

1x2

1.5*2

2x3

2*4

Support Rod

1.5x2.5

2x3

1.5x2.5

2x3

1.5x2.5

2x3

1.8*2.5

2x3

3*5

3*5

Connection

Flange and thread

End Type

Closed plate

Note

Customized According To Special Requirement

The Packaging and Transportation of the Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap:

Stainless Steel Wire Wrapped Filter Screens Water Treatment Resin Trap
