Wedge wire water lateral distributor

More Views

Wedge wire water lateral distributorWedge wire water lateral distributorWedge wire water lateral distributor

Wedge wire water lateral distributor

Category:Profile screen laterals
Material:stainless steel 304,304L,304HC,316,316L,321,430 or as per your request.
Properties:water distributor
Application:water treatment, water well, food treatment, chemical industry, papermaking industry, decoration.

if you are interested in receiving more information or have a question regarding any of our products please fill out the form above and we will contact you within 24-48 hours.

Skype:yolanda

Detailed description of the Wedge wire water lateral distributor

Wedge wire water lateral distributor is made of V shaped stainless steel wire. It has flow area, water distribution uniformity, the high mechanical strength, temperature,pressure,anti aging, anti corrosive has been greatly enhanced. Stainless steel wire around the space under the index finger to the size of the design.

Wedge wire water lateral distributor

Application of Wedge wire water lateral distributor

application in deep well pump to dive the water pump, in the water-treating equipment, the environmental protection, the sea water transforms into the industrial water and life use water desalination treatment, running water treatment, water softening treatment; the petroleum industry, the petroleum product terminal filters; and the chemical acid, the alkali liquid filters, the ethyl alcohol and the organic solution recycling filters.

Features of Wedge wire water lateral distributor

1. Screens with high open area are more suitable for the construction of high-quality water wells, oil wells and gas wells.
2. Low cost operation.
3. Reduce the abrasion of the pump.

Wedge wire water lateral distributor

Wedge wire water lateral distributor





The specifications of the Wedge wire water lateral distributor:

Wedge wire water lateral distributor is made of V shaped stainless steel wire. It has flow area, water distribution uniformity, the high mechanical strength, temperature,pressure,anti aging, anti corrosive has been greatly enhanced. Stainless steel wire around the space under the index finger to the size of the design.

Material:
stainless steel (304,316etc.)
Wedge Wire (mm):
Width : 0.75 1.50 1.80 2.30 3.00 3.30 3.70
Support Rod (mm):
Width : 1.00 1.80 2.00 3.00 4.00 5.00
Height : 2.00 2.50 3.00 5.00 6.00 8.00
Branch pipe OD:
Up to 1.0 meter
Branch pipe Length:
lengths up to 6 meters.
Main hub pipe
as your special requirement
Slot size:
0.02,0.05,0.1 0.15, 0.20, 0.25, 0.30,....., 3.00 also achieved upon request.
Note:
Other specifications can be customized according to your requirement



The Packaging and Transportation of the Wedge wire water lateral distributor:

Wedge wire water lateral distributor
